DI-V3 |
DI-PSU for DI-V3 |
概述 | 使用指引 | 规格 | 技术细节 | 定制选项 |
Specifications might subject to change without prior notice for product improvement. |
|
Power supply |
USB power or extern DC5 to DC9V (450MA or more) |
Output Level |
0.5 Vp-p (at 75 Ohms) @ SPDIF 3.3V p-p (25MA) @ I2S |
Input Sensitivity |
0.5 Vp-p(75 Ohms, Coaxial) USB1.1 ,USB2.0 (Full Speed, High Speed, Class2) |
Support Sampling (Input) |
USB model : 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz ,352.8kHz ,384kHz Coaxial model: 44.1kHz, 48kHz, 88.2kHz, 96kHz, 192kHz |
Support Sampling (output) |
Coaxial model: 44.1kHz to 192kHz USB to I2S model : 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz ,352.8kHz ,384kHz Coaxial to I2S model: 44.1kHz, 48kHz, 88.2kHz, 96kHz, 192kHz |
Power Consumption |
400MA |
Package Weight |
Approximately 1KG |
Dimensions |
W163 X L120 X H42 (MM, Fully aluminium ) |
Accessories |
USB cable X1 |
